The E-type ran from 24 August 1951 to August 1957, a monocoque body over three different engine stages. Until April 1952 it carried the L-type engines over. Then came the short-stroke 1,508cc four (79.3 × 76.2mm) and 2,262cc six. In June 1957 the six was redesigned on the deeper Victor F block. Brakes are Lockheed-Vauxhall hydraulic drums, 9.13in, and the front suspension is coil and wishbone with the dampers inside the coils and an anti-roll bar, leaf springs at the rear, Burman recirculating-ball steering. 110,588 Wyverns, 235,296 Veloxes and, from October 1954, 166,504 Crestas were built.
The E-type and the Bedford CA van are close relatives. The 1,508cc four is the CA’s engine, and one 1952 Vauxhall shop manual covers both — MOTAT holds a copy. For glass and body, the model years matter: the ’55 cars (August 1954) got a new grille and bonnet, flashing indicators and a front-opening bonnet; the ’56 cars (October 1955) deeper screens, slimmer pillars, a wrap-round rear window and wind-up windows; the ’57 cars a new grille, larger tail lamps and electric wipers. Estates came only in 1957, from Grosvenor and Dormobile. The E-type Velox and Wyvern were assembled at Petone.
Vauxhall Wyvern, Velox & Cresta E-Type — specification & changes within the model
- Codes
-
EIX = Wyvern. EIP = Velox. EIPV = the Velox with the 1952 engine. Cresta = EIPC — not EIPV, as often printed. Australian chassis-only versions are EBX and EBP.
- Engines — three stages
-
To April 1952: the L-type 1,442cc four and 2,275cc six. April 1952: short-stroke 1,508cc four and 2,262cc six. June 1957: a redesigned 2,262cc six on the Victor F block. Know which you have before ordering engine gaskets.
- Brakes
-
Lockheed-Vauxhall hydraulic drums, 9.13in, the same on Wyvern and Velox as on the Cresta.
- Suspension & steering
-
Coil and wishbone front, dampers inside the coils, anti-roll bar; leaf rear. Burman recirculating ball.
- Glass — the ’56 split
- From October 1955: deeper front and rear screens, slimmer pillars, a wrap-round rear window and wind-up windows. Check the year before ordering glass rubbers.
- Wipers
- Engine-driven until 1957, then electric.
- Bedford CA
-
The CA runs the E-type’s 1,508cc four, and the two share a 1952 shop manual.
- Earth polarity
-
We cannot tell you, and we will not guess. We could not find one source we trust that gives the earth polarity for the E-type, and none gives a changeover date. Check the car before you order a coil, a regulator or a radio.
